(cnc.1)CNC BOHRWERK -FEMCO-BMC 110 -R3-Model 2005

FIVE AXIS   X=3000      Y=1800      Z=1700     W=550 mm.      B-360°  Rotary Table

MAX. WORKPIECE MATERIAL WEIGHT= 6,5 TON.



Click to see the pictures of CNC BOHRWERK  machining center

(cnc.02)CNC MORİ SEİKİ NH4000DCG JAPON-Model 2008

MORI SEIKI HORIZONTALCENTRE

FOUR AXIS=X-560.mm. Y-560.mm   Z-630.mm   B-360°  two tables

(cnc.03)CNC MORI SEIKI NH5000DCG JAPON-Model 2007

MORI SEIKI HORIZONTALCENTRE

FOUR AXIS=X-730.mm. Y-730.mm   Z-850.mm   B-360°  two tables

(cnc.04)CNC MORI SEIKI NH4000DCG JAPON-Model 2006

MORI SEIKI HORIZONTALCENTRE

FOUR AXIS=X-560.mm. Y-560.mm   Z-630.mm   B-360°  two tables

(cnc.05)CNC TORNA-GOODWAY-GS 400L-Model 2008

Max. Swing Diameter : Ø740 mm. - Max. Turning Diameter : Ø610 mm

Max. Turning Length : 1990 mm. – Turning Chuck : 15” – Spindle Bar Capacity : Ø115 mm.

Programmable Base and Quill Hydraulic Tailstock Capacity : Ø50-Ø200 mm


(cnc.06)CNC  TURNING CENTER -ALEX.TECH-ANL-52T -Model 2001

TWO AXIS =  X=400   Z=450  mm.  8"

(cnc.07)CNC TURNING CENTER-VICTOR-VTURN-20 -Model 2002

TWO AXIS=  X=235   Z=650  mm.   8"

(cnc.08)CNC TURNING CENTER-TAKANK-TNC-30L-Model 2006

TWO AXIS= X=420   Z=1090 mm.   10"

(cnc.09)CNC TURNING CENTER-GOODWAY-TNC-30L-Model 2006

TWO AXIS= X=420   Z=1090 mm.   10"

(cnc.10)CNC VERTİCAL MACHİNİNG CENTER -FEELER-FV 100 -Model 2004

THREE AXIS=1000 X 500 X 500 mm.

(cnc.11)CNC VERTİCAL MACHİNİNG CENTER -STARWAY-VMC-1270-Model 2004

FOUR AXIS=1200 X 700 X 650  X DIVISOR diameter= 250.mm





(cnc.12)CMM 3D MEASURING-MITUTOYO-CRT-A C575-Model 2004

TP10 type measuring prob accuracy:(20°±1K) X=650   Y=1100    Z=450  mm.



FT-400 PNAUMATIK TAPPING MACHINE-Model 2006

AMONG Metric 4 - to – Metric  24
